ScreenMaster RVG200
Paperless recorder 4 Operation
OI/RVG200-EN 47
Max/Min Reset
Bargraph views only
Note. Greyed-out if the Max / min reset menu enable is not selected – see
page 85.
Touch to reset the maximum and minimum value markers on one or all
channels to the current value.
Note.
 These maximum and minimum values are for display purposes only.
They are not saved or archived and are not connected to the totalizer
maximum and minimum values displayed in the Indicator view.
 These maximum and minimum values are reset whenever the current
configuration has been changed or is re-saved.
Filter Select
Alarm Event and
Totalizer log views only
Select the entries to be displayed in the log.  Indicates entries selected.
Note.
 Hiding and displaying log entries does not affect the recording of
events in the log.
 All selected alarm event transitions (from inactive to active, from
active to acknowledged, from acknowledged to inactive, from active
to inactive) appear in the sequence in which they occurred.
 Selecting Active Transitions Only displays entries for alarms when
made active and hides all acknowledged and inactive transitions.
 To quickly select all entries, touch followed by .
