ScreenMaster RVG200
Paperless recorder 4 Operation
46 OI/RVG200-EN
Input Adjust Note. Displayed only if Operator Calibrate on one of the Analog I/P
configuration tabs is set to On – see page 113.
Touch to manually fine-tune inputs to remove process offset errors or
system scale errors for the selected input.
Note. All totalizer menu items are greyed-out if the totalizer software option is not enabled.
Totalizer Stop / Go
Indicator and overview
display views only
Note. Greyed-out if the relevant Totalizer stop / go menu enable is not
selected – see page 84.
Touch to stop and start individual totalizers.
Note. When a totalizer is not running (Stop has been selected), the
corresponding totalizer value is shown in red.
Totalizer Reset
Indicator and overview
display views only
Note. Greyed-out if the relevant Totalizer reset menu enable is not
selected – see page 84.
Touch to reset the totalizer value to the totalizer preset value.
Show Statistics
Show Totalizers
Indicator and overview
display views only
Note. Greyed-out if the Show totalizers / statistics menu enable is not
selected – see page 84.
Touch Show Statistics / Show Totalizers to toggle between the totalizer
value display and totalizer statistics display (totalizer maximum, minimum
and average values).
If both totalizers on one channel are enabled and:
Show Totalizers is selected – the tag, current value and units for
both totalizers are displayed together in the channel's indicator.
Show Statistics is selected – the tag, units, maximum, minimum
and average values for each totalizer are displayed in turn for 5
seconds in the channel's indicator.
Show Totalizer Values
Show Channel Value
Indicator and overview
display views only
Touch Show Totalizer Values / Show Channel Value to toggle between the
totalizer value display and instantaneous channel value display.
Note. Greyed-out when more than 6 channels are displayed.
