UPDATING THE SOFTWARE

Art: 714380-00M Rev. Date: 06-Mar-12 18-1

For instructions on updating your i-STAT 1 Handheld, please refer to the following

Technical Bulletins directly following section 18 in your i-STAT 1 System Manual:

1. Instructions for Updating i-STAT 1 Handheld Software

(Art. 725708-00E).

2. Network Options for Updating the i-STAT 1 Handheld

(Art. 725768-00E).
