Abbott i-STAT 1

To Next Page

To Previous Page

7 - 6

Art: 714369-00H Rev. Date: 03-Aug-12

THE i-STAT PRINTER

OVERVIEW

This section describes the instructions for using the new i-STAT Printer, which is used to print results from

all models of the i-STAT 1 Analyzer (handheld).

Note: This printer cannot be used with the i-STAT Portable Clinical Analyzer (PCA).

Power

Button

Paper

Feed

Button

Power

Indicator

Status

Indicator

Window

Paper

Release

Lever

Power

Button

Paper

Feed

Button

Power

Indicator

Status

Indicator

Window

Paper

Release

Lever

Data

Connection

Power

Connection
