Art: 714383-00F Rev. Date: 02-Sep-08 21-7

Option 2: The following diagram shows how to connect the portable printer

to the network Downloader for power and communication. Parts

required are:

• Printer Interface Cable

• Printer AC Adapter or Printer Power Cable

 Power In

 Power Out

 RJ12 (printer interface)

DB9

 RJ45 (network)
