Abbott Point of Care Inc. • Abbott Park, IL 60064 • USA

Art: 721106-00B Rev. Date: 06/11/08

Technical BulleTin

i-STAT

APRIL 2008 UPDATE TO THE i-STAT CENTRAL DATA

STATION VERSION 5

QUALITY CHECK CODES VIEWER

A new column has been added to the Quality Check Codes Viewer indicating the Quality Code Category

corresponding to the individual quality check code.
