MC81F4204
April 24, 2012 Ver.1.41 97
T1DR
TIMER 1 DATA REGISTER 00B4H
7 6 5 4 3 2 1 0
T1DR
One byte register Reset value: FFH
R/W R/W R/W R/W R/W R/W R/W R/W
A 8-bit compare value register for the timer 1 match interrupt.
T1CR
TIMER 0 COUNTER REGISTER 00B5H
7 6 5 4 3 2 1 0
T1CR
One byte register Reset value: 00H
R R R R R R R R
A 8-bit count register for the timer 1
