3-22 Machine Maintenance Procedures
WLAN Module Installation 0
1. Connect module to mainboard connector (E) (Figure 3-19).
2. Install and secure screw (D) to mainboard.
3. Install main (B) and auxiliary (C) antenna cables on WLAN module connectors.
4. Install base door.
ID Size Quantity Screw Type
D M2.0x3.0 1
SG_JV51_HR.book Page 22 Friday, July 8, 2011 5:58 PM
