1-16 Hardware Specifications and Configurations
Base View 0
Figure 1-5. Base View
Table 1-5. Base View
# Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery release latch/
lock
Releases the battery for removal.
Insert a suitable tool into the latch and slide to
release.
3 Memory compartment Houses the computer's main memory.
Hard disk bay Houses the computer's hard disk (secured with
screws).
