3-20 Machine Maintenance Procedures
ODD Module Installation 0
1. Install bezel (G) to module (Figure 3-17).
2. Install bracket (D) to module.
3. Install and secure two (2) screws (C).
4. Install module in lower cover (Figure 3-14).
5. Install and secure screw (A) to lower cover.
6. Install HDD module.
ID Size Quantity Screw Type
A M2.45x8.0 1
C M2.0x3.0 2
SG_JV51_HR.book Page 20 Friday, July 8, 2011 5:58 PM
