Acer Aspire 5755 - Card Reader

Jumper and Connector Locations 5-7
Card Reader 0
Figure 5-7. Card Reader Top
Figure 5-8. Card Reader Bottom
Table 5-5. Power Board
Item Description
JSIM1 SIM Card Connector
JMINI1 MINI Card Connector
J3G1 3G Board Connector
