2-20 System Utilities
Remove HDD/BIOS Password Utilities 0
This section provides details about removing HDD/BIOS passwords.
Remove HDD Password as follows:
If the HDD password is incorrectly entered three times, the Password
Error Status dialog shown. (Figure 2-22)
Figure 2-22. Password Error Status
To reset the HDD password, perform the following:
1. Press Enter to continue. The Select Item dialog is shown. (Figure 2-23)
Figure 2-23. Select Item
2. Use the and keys to highlight Enter Unlock Password and press Enter. The
Enter Unlock Password dialog box appears. (Figure 2-24)
Figure 2-24. Enter Unlock Password
A key code is generated for use with unlocking utility. Make note of this code.
3. On separate, compatible device, boot to DOS.
SG_JV51_HR.book Page 20 Friday, July 8, 2011 5:58 PM
