Acer Aspire 5755 - Upper Cover Removal

Machine Maintenance Procedures 3-29
Upper Cover Removal 0
Prerequisite:
Palmrest Assembly Removal
ODD Module Removal
1. Remove 10 screws (A) from upper cover (Figure 3-28).
Figure 3-28. Upper Cover Screws
2. Remove five (5) screws (B) from lower cover battery bay. (Figure 3-29)
Figure 3-29. Battery Bay Screws
3. Place computer face up.
A
A
A
B
