Jumper and Connector Locations 5-5
USB Board 0
Figure 5-3. USB Board Top
Figure 5-4. USB Board Bottom
Table 5-3. USB Board
Item Description
JUSB1 USB2.0 Connector
JUSB2 USB3.0 Connector
JUSB3 USB3.0 Broad Connector
JUSB4 USB2.0 Broad Connector
JP1 WLAN EN Connector
SW1 WLAN EN Switch
