Acer Aspire 5755 - LCD Bezel Removal

Machine Maintenance Procedures 3-55
LCD Bezel Removal 0
Prerequisite:
LCD (Liquid Crystal Display) Module Removal
1. Locate the LCD Bezel (A) on the LCD module (Figure 3-59)
Figure 3-59. LCD Module Overview with Bezel
2. Remove the two (2) mylar covers and two (2) screws (C) from module. (Figure 3-60)
Figure 3-60. LCD Module Bezel Screws
A
B
B
CC
