Machine Maintenance Procedures 3-61
LVDS Cable Installation 0
1. Connect LVDS cable (C) to panel connector (D) (Figure 3-67).
2. Secure connector with adhesive (B).
3. Install and secure LVDS cable (D) to LCD panel (Figure 3-66).
4. Install LCD Panel.
