3-30 Machine Maintenance Procedures
5. Disconnect microphone cable (L) from mainboard connector (M). (Figure 3-29)
Figure 3-29. Microphone Cable and Mainboard Connector
6. Remove two (2) screws (N) from lower cover. (Figure 3-30)
Figure 3-30. Mainboard Screws
7. Hold lower cover (P) while lifting the mainboard at bridge section (Q). (Figure 3-31)
Figure 3-31. Mainboard Bridge
L
M
N
N
P
Q
