5-6 Jumper and Connector Locations
3. Short two points of jumpers (A). (Figure 5-4)
Figure 5-4. CMOS Jumper
4. Plug in AC adapter.
5. Press Power button until BIOS POST is finished
6. Remove conductivity tool from RCT_RST point.
7. Restart the system and press F2 to enter BIOS Utility Setup menu.
8. If no password prompt is shown, BIOS password is cleared.
9. If password prompt is shown, repeat steps 1 through 9.
Table 5-3. CMOS Jumper
Item Description
CLRP1 Clear CMOS Jumper
