3 System Description
Injector Head
e injector head houses the motors, pumps, sensing elements, and soware
that control the delivery of contrast and saline. e injector head includes
safety features to support the safe delivery of angiographic uid media,
including the following:
• Air column detect sensor to aid the user in the detection of air being
introduced into patient tubing.
• Contrast sensor for detection of contrast in the contrast tubing.
• Manifold valve sensor to detect manifold position.
• Syringe valve sensor for detection of the syringe valve ball position.
• Luminescent backlight to facilitate visual detection of air.
Mounting
e injector head can be mounted in the following ways:
• On a movable pedestal cart, with the control panel mounted onto the
injector head.
• On a bed rail, with the control panel mounted onto the injector head.
• On a bed rail, with the control panel mounted separately.
Air column detect sensor
Contrast sensor
Syringe valve sensor
Manifold valve sensor Luminescent backlight
