ACIST | CVi® System User's Guide 901418-003,01 2019-08 English (USA) | 37
Load Saline Tubing Assembly4 Setup
9. Press DONE on the touchscreen to ll the syringe.
Warning
It is important to use aseptic technique throughout this procedure. See
Aseptic Technique on page 6 for more information.
1. Remove the white protective cover from the BT2000 pressure
transducer and connect the transducer cartridge to the transducer
backplate sensor.
Note
A hemodynamic monitoring cable is required. The cable type is
dependent upon the type of monitoring equipment used. Contact
ACIST Medical to obtain the correct transducer interconnect cable.
Air vent
White slide clamp
Load Saline
Tubing Assembly
To Next Page
