Push the buttons and their statuses are
indicated by various colors:
1. Light Blue: Push button.
2. Dark Blue: focused push button.
3. Yellow: (in Functions field):
parameter value set automatically
4. Green: selected push button if the
push button features a parameter for
setting a value, it can now be
changed.
5. Orange: parameter is automatically
adjusted by the device.
.
The value that you set indicates the
maximum value and will NOT be
exceeded.
Depending on the Ventilation mode, the
ventilation menu indicates the
configuration parameters (4) and
measurements (2) relevant in the mode.
Using the push button, you can also
switch between the Pressure-, Volume-
and Flow curve (3).
The Information bar (1) indicates current
information.
The ventilation mode can be changed in
the menu (5).
