12.2 etCO
2
monitoring
12.2.1 etCO
2
Sensor module types and selection
The fabian HFO supports three different etCO
2
module types to provide etCO
2
monitoring:
1. Microstream, MicroPod™ External etCO
2
Module from Oridion
®
(Covidien/Medtronic)
2. Capnostat® 5 Mainstream etCO2 Sensor from Respironics® (Philips).
3. LoFlo Sidestream etCO2 Sensor from Respironics (Philips).
NOTE:
Only one module at a time can be connected and used with the ventilator.
The module can be activated in the etCO
2
submenu of Calibration view of fabian HFO (Figure 1 /
Figure 2).
Figure 1 - fabian HFO Calibration menu
Figure 2 - etCO
2
Sensor submenu
