ACUTRONIC fabian HFO User Manual

38 System functions and displays
fabian HFO | SW 5.1.x
Ref: 113003.EN / Date 2020-02-10
The Trend menu features three
simultaneous parameters as curves.
The Parameters displayed can be
modified by activating the Select List on
left side.
Available parameters are:
• % MVmand
• Compliance
• DCO
2
• etCO
2
• FiO
2
• Freq
• HF Amplitude
• Leak
• MV
• Pinsp
• Pmean
• Resistance
• RSBI
• SpO
2
• SpO
2
PI
• SpO
2
PR
• Vte
Shifting the Timeline.
The Timeline can be shifted for all three
parameters simultaneously.
1. Change timeline from the Rotary
Pulse encoder or soft keys.
