ACUTRONIC fabian HFO User Manual

52 System operation
fabian HFO | SW 5.1.x
Ref: 113003.EN / Date 2020-02-10
What
How
Target
• Test lung
Switch ON
test
1. Switch ON the fabian ventilator.
2. Perform the acoustic audible alarm test.
3. Confirm that the audible tone can be heard
Alarm tone is audible and
alarm lamp flashes Red
during switch-ON test.
Self-test successful.
Calibration
Calibrate Flow sensor.
Calibrate O
2
sensor (occurs automatically after
leaving Calibration menu).
Calibration successful
Leakage
Test
Start ventilation mode: CPAP
1. Enter the following settings:
• CPAP: 5 mbar
• Pmanual: 80 mbar
2. Press and hold the Manual
Breath button
Pressure of 80 ±4 mbar
is achieved on the pressure
graph
Caution:
Ensure that Pmanual and other
pressures are reduced to
safe levels prior to connecting
to patient.
Function
Test
Start Ventilation mode: IPPV
Enter the following settings:
• I‒flow: 10 Lpm
• E‒flow: 8 Lpm
• PEEP: 5 mbar
• Pinsp: 20 mbar
• Freq. (Rate): 30
1 / min
• I‒time: 1 second
• Oxygen: 30 vol.%
Monitor ventilation
parameters to ensure the
values are within the
following ranges.
P insp.: 20 ±2 mbar
PEEP: 5 ±1 mbar
O
2
: 30 ±2 Vol %
Alarms
Disconnect the inspiration tube and block the
inspiratory port on the ventilator.
Alarm: Tube Occlusion
Disconnect the expiration tube and block the
opening of the expiratory tube.
Alarm: Tube Occlusion
Crimp and hold Proximal Measurement tube.
Alarm: Tube Occlusion
Humidifier
Fill level
Function
Water fill level sufficient.
Function OK
CAUTION:
Ensure that Pmanual and other pressures are reduced to safe levels prior to connecting to
patient.
