99 18 Electromagnetic compatibility statement
fabian Therapy evolution | SW V5.1.x
Ref: 121003.EN / Date: 26Jan2021
Guideline and Manufacturer Declaration – Electromagnetic Immunity
The fabian Therapy evolution device is intended for operation in the environment described below. The
customer or operator of the fabian Therapy evolution apparatus should ensure it is operated in this type of
environment.
Electromagnetic Environment – Guideline
Electrostatic
Discharge (ESD)
IEC 61000-4-2
Air: ±2kV, ±4kV, ±6kV, ±8kV, ±15kV
Contact: ±2kV, ±4kV, ±6kV, ±8kV
Floors should be wooden or concrete or tiled with
ceramic tiles. For flooring made from synthetic
materials, the Relative Air Humidity must be no
less than 30%.
Electric Fast
Transients & Burst
IEC 610004-4
AC Power Leads: ±2kV
SIP/SOP & Control ports: ±1kV
(All cable lengths tested)
The Mains quality should correspond to typical
business or hospital environments.
Differential Mode (Lead-to-Lead)
±0.5kV, ±1kV
Common Mode (Lead-to-Ground)
±0.5kV, ±1kV, ±2kV
The Mains quality should correspond to typical
business or hospital environments.
Power Frequency
Magnetic Fields
IEC 61000-4-8
Magnetic areas at the Mains frequency should
correspond to typical values in business and
hospital environments.
Voltage Dips,
Interruptions &
Voltage Variations
IEC 61000-4-11
0%
U
T
(100% dip of
U
T) for 0.5 cycles at
various phase angles; 0, 45, 90,
135, 180, 225, 270, 315
0%
U
T
(100% dip of
U
T) for 1 cycle at a
phase angle of 0.
40%
U
T
(60% dip of
U
T) for 5 cycles at a
phase angle of 0.
70% U
T
(30% dip of
U
T) for 25 ∕30 cycles at
a phase angle of 0.
0%
U
T
(100% dip of
U
T) for 250 ∕300 cycles
at a phase angle of 0.
The Mains quality should correspond to typical
business or hospital environments. If the operator
of the fabian Therapy evolution requires
continued use in the event of a power failure, we
recommend connecting the fabian Therapy
evolution to an uninterruptible Mains supply or a
Battery.
REMARK :
U
T is the Mains alternating voltage before applying the Test Level.
