5.1.1 Connect the power supply
Connect the fabian with power cable to a suitable power outlet.
WARNING
:
DO NOT connect the device to a power outlet strip.
Power fluctuations from the system may trip the circuit breaker in the power outlet strip
causing loss of power to the device.
Exception: An approved medical grade power outlet strip with valid amperes rating by the
manufacturer for connection to a ventilator.
The device can be operated with 100 to 240 VAC, 50 or 60 Hz and automatically adjusts to voltage
and frequency without manual switch-over being necessary.
WARNING
:
The use of fuses must correspond with the value and type approved for the fabian.
• The fuse type and value is printed on the back of the fabian.
• Replacement of the fuses can only be carried out by trained staff. Replace fuses with
identical values. Failing to do so, can cause fire hazards.
WARNING
:
To avoid risk of ELECTRIC SHOCK, this equipment must only be connected to a Supply
Main with protective earth ground.
5.1.2 Connect the gas supply
Connect the compressed air and oxygen supply tube to the back of the device and to the Central
Gas Supply.
If there is no central gas supply, gas supply from cylinders is also possible. Use cylinder with
approved regulator per CGA/ISO standards, including fill indicators.
The inputs are coded to prevent wrong connection.
Medical grade oxygen and medical grade AIR (
dust-free, oil-free and dry,
2.0 to 6.0 bar) are
required.
