ACUTRONIC fabian User Manual

17 Technical specifications 92
fabian Therapy evolution | SW V5.1.x
Ref: 121003.EN / Date: 26Jan2021
Dimensions / Weight
W x H x D
24 cm x 27 cm x 35 cm
Weight
≈ 9 kg
Ratings
Device fuse
T 630 m A L (from SN xxxxxx-0159 T 1 A L)
Electrical Safety Classification
Class I (mains power)
Internally powered (battery power)
Internal Battery
13.2 V / 4500 mAh
maximum Charging time: 5 hours
Fuse: 3 AT
Battery charge is continuously monitored
Battery life: 3 hour
Battery type: NiMH
IP Protection
From SN AT-04000: IP22
Till SN AT-03999: IPX1
Oxygen Supply
From SN AN-04000: 2.0 to 6.0 bar / max. 40
L/min
Till SN AN-03999: 2.0 to 6.5 bar / max. 40
L/min
Connection thread: NIST
NOTE : Medical grade Oxygen
Power Rating
DUOPAP mode: max. 70 W
Standby, fabian connected to mains: 35 W (Battery
charging)
Power Supply
100 to 240 VAC
0.4 to 0.8 A
50 / 60Hz
Till SN AT-03999: External 12 to 24 VDC 3 AT
(Charging only when more than 12.5V)
Pressurized Air Supply
From SN AT-04000: 2.0 to 6.0 bar / max. 40
L/min
Till SN AT-03999: 2.0 to 6.5 bar / max. 40
L/min
Connection thread: NIST
NOTE : Medical grade Air
Safety Classification (Applied Parts)
From SN AT-04000: Type BF
Till SN AT-03999: Type B
Electrical Safety Classification
Class I (mains power)
Internally powered (battery power)
Sound pressure
Max. 68 dB (A)

ACUTRONIC fabian Specifications

General

Type	Neonatal and Pediatric Ventilator
Manufacturer	ACUTRONIC Medical Systems AG
Model	fabian
Respiratory Rate	1 - 150 bpm
FiO2 Range	21 - 100%
HFOV Frequency	5 - 20 Hz
Power Supply	100-240 V AC, 50/60 Hz
Modes of Ventilation	SIMV, CPAP, HFOV
Tidal Volume Range	2 to 300 ml
PEEP/CPAP	0-20 cmH2O
Inspiratory Time	0.1 to 3 seconds
Flow Rate	2 - 30 L/min
Flow Sensor	Integrated
Pressure Limit	10-80 cmH2O
