ACUTRONIC fabian User Manual

15 Sterilization / cleaning / disinfection 84
fabian Therapy evolution | SW V5.1.x
Ref: 121003.EN / Date: 26Jan2021
15 Sterilization / cleaning / disinfection
fabian Therapy evolution
The device must be prepared after each patient treatment.
WARNING :
The device must NOT be sterilized under any circumstances.
15.1.1 Preparation for disinfection
1. Switch OFF the fabian before cleaning and unplug at the mains in order to prevent damage
due to penetration by liquid.
Figure 15-1: Unplug mains connection
2. To ensure that no contamination gets into the gas path, make sure all gas connectors (O
2
and Air hoses on the backwall, Insp port and Prox port on frontside) are covered (e.g. with
caps from transport or circuits) before cleaning.
3. Remove any visible soiling on the fabian enclosure with the cleaning agent based on the
option selected from Section 15.1.2:”Manual disinfection options”.

ACUTRONIC fabian Specifications

General

Type	Neonatal and Pediatric Ventilator
Manufacturer	ACUTRONIC Medical Systems AG
Model	fabian
Respiratory Rate	1 - 150 bpm
FiO2 Range	21 - 100%
HFOV Frequency	5 - 20 Hz
Power Supply	100-240 V AC, 50/60 Hz
Modes of Ventilation	SIMV, CPAP, HFOV
Tidal Volume Range	2 to 300 ml
PEEP/CPAP	0-20 cmH2O
Inspiratory Time	0.1 to 3 seconds
Flow Rate	2 - 30 L/min
Flow Sensor	Integrated
Pressure Limit	10-80 cmH2O
