ACUTRONIC fabian User Manual

91 17 Technical specifications
fabian Therapy evolution | SW V5.1.x
Ref: 121003.EN / Date: 26Jan2021
Measuring
Airway measurement Range:
Accuracy
2
:
Resolution:
–10 to 110 mbar
±4%
0.1 to 1 mbar
Inspiratory Oxygen Concentration:
Inspiratory O
2
Concentration Range:
18 to 100 Vol%
Max. error delivered vs. set FiO
2
with Oxygen monitoring
2
:
3% FiO
2
Max. error delivered vs. set FiO
2
without oxygen monitoring
2
:
5% FiO
2
Response Time to change in FiO
2
:
Conventional Ventilation: blender delay is 1 breath.
Total Delay = Blender Delay + Pneumatic Delay
Drift:
Pressure Influence:
Warm-Up Time:
<1 Vol% per month. <15% rel. over entire service life
Proportional to change in Partial Pressure
max. 3 minutes (<30 minutes with New O
2
Sensor)
Ventilation menu settings
Automatic O
2
calibration
• 21% Vol.
• 21% Vol. and 100% Vol.
Flush time (O
2
)
• OFF
• 30 seconds
• 60 seconds
• 120 seconds
Max time manual breath
• 2 to 30 seconds
NIV Leak compensation
• OFF/ Low / Middle / High
NIV Tube set
• MediJet
• Infant Flow ( Infant Flow or Inspire )
• Infant Flow LP
Ratio of I-time
• Frequency/I–time
• I–time/E-time
Unit for pressure
• mbar
• cmH
2
O
2
Measurement uncertainty during performance verification
For pressure measurements: ± 1.75% of reading or 0.1 mbar (whichever is greater)
For volume measurements: ± 1.75% of reading or 0.1 mL (whichever is greater)
For oxygen level measurements: ± 1% absolute

ACUTRONIC fabian Specifications

General

Type	Neonatal and Pediatric Ventilator
Manufacturer	ACUTRONIC Medical Systems AG
Model	fabian
Respiratory Rate	1 - 150 bpm
FiO2 Range	21 - 100%
HFOV Frequency	5 - 20 Hz
Power Supply	100-240 V AC, 50/60 Hz
Modes of Ventilation	SIMV, CPAP, HFOV
Tidal Volume Range	2 to 300 ml
PEEP/CPAP	0-20 cmH2O
Inspiratory Time	0.1 to 3 seconds
Flow Rate	2 - 30 L/min
Flow Sensor	Integrated
Pressure Limit	10-80 cmH2O
