ACUTRONIC fabian User Manual

12 Accessories and options 76
fabian Therapy evolution | SW V5.1.x
Ref: 121003.EN / Date: 26Jan2021
12.4.2 Setting up PRICO
PRICO can be activated in the SpO
2
section of the Graphics menu. PRICO will adjust the FiO
2
, to
keep the SpO
2
within the selected range.
Figure 12-10: PRICO in fabian Therapy Alarm Limits menu
PRICO has the following parameters:
PRICO Parameters
Min FiO
2
Minimum allowed FiO
2
.
Range: 21
to 99%
Max FiO
2
Maximum allowed FiO
2
.
Range: 22
to 100%.
SpO
2
low target
The lower target for SpO
2
.
Range: 0
to 99%.
SpO
2
high target
The higher target for SpO
2
.
Range: 1
to 100%.
PRICO ON/OFF
ON /OFF switch for PRICO
Dependencies on Alarm Limits:
• “SpO
2
low target” must be greater than or equal to the low SpO
2
alarm limit.
• “SpO
2
high target” must be less than or equal to the high SpO
2
alarm limit.
• PRICO can only be “ON” when the measured SIQ (Signal Quality) is higher than the SIQ alarm
limit.
Due to the dependencies of the PRICO alarm limits it is critical that you first select
the appropriate alarm limits for the patient, before switching on PRICO.

ACUTRONIC fabian Specifications

General

Type	Neonatal and Pediatric Ventilator
Manufacturer	ACUTRONIC Medical Systems AG
Model	fabian
Respiratory Rate	1 - 150 bpm
FiO2 Range	21 - 100%
HFOV Frequency	5 - 20 Hz
Power Supply	100-240 V AC, 50/60 Hz
Modes of Ventilation	SIMV, CPAP, HFOV
Tidal Volume Range	2 to 300 ml
PEEP/CPAP	0-20 cmH2O
Inspiratory Time	0.1 to 3 seconds
Flow Rate	2 - 30 L/min
Flow Sensor	Integrated
Pressure Limit	10-80 cmH2O
