ACUTRONIC fabian User Manual

6 Configurations menu 40
fabian Therapy evolution | SW V5.1.x
Ref: 121003.EN / Date: 26Jan2021
6.2.1 Touch screen settings
Lock Touch screen:
In the Touch area of the Display
screen, press “lock” and the
screen is locked.
NOTE : To deactivate the lock, press
the Rotary Pulse knob.
Program automatic lock. Slide
the bar to the right and the
Time will be displayed.
Lock is automatically cancelled in the
event of an alarm or by pressing the
Rotary Pulse knob.
Select Time and you can
choose the appropriate time
from the list.
NOTE : Exit the time menu with the
Return button and the chosen time
will be displayed.
The touch screen can also be locked
by holding the Rotary Pulse knob for
3 seconds.
Figure 6-7: Lock screen time settings
1
2
3

ACUTRONIC fabian Specifications

General

Type	Neonatal and Pediatric Ventilator
Manufacturer	ACUTRONIC Medical Systems AG
Model	fabian
Respiratory Rate	1 - 150 bpm
FiO2 Range	21 - 100%
HFOV Frequency	5 - 20 Hz
Power Supply	100-240 V AC, 50/60 Hz
Modes of Ventilation	SIMV, CPAP, HFOV
Tidal Volume Range	2 to 300 ml
PEEP/CPAP	0-20 cmH2O
Inspiratory Time	0.1 to 3 seconds
Flow Rate	2 - 30 L/min
Flow Sensor	Integrated
Pressure Limit	10-80 cmH2O
