ACUTRONIC fabian User Manual

3 System overview 8
fabian Therapy evolution | SW V5.1.x
Ref: 121003.EN / Date: 26Jan2021
3 System overview
Scope of Delivery
The fabian Therapy product includes the following items:
• One - fabian Therapy evolution ventilator
• Two - Infant Flow Ventilator Tubes
• One - Power cable (# country specific )
• One - Operating manual (# country specific )
• NOTE: The duration of indirect patient contact is defined as prolonged (i.e. more than 24
hours and less than 30 days)
Contraindications
Severe airflow obstruction, and intracranial hypertension, would contraindicate the use of the
fabian Therapy evolution neonatal and infant ventilator.
In the event of ventilation for more than several hours, care must be taken for optimal
conditioning of the respiratory gases ( warmth, humidification ) to optimize secretion mobilization
and prevent damage to mucous membranes.
fabian Front connections
1
Connection for fresh gas
2
Pressure measuring tube port
1
2

ACUTRONIC fabian Specifications

General

Type	Neonatal and Pediatric Ventilator
Manufacturer	ACUTRONIC Medical Systems AG
Model	fabian
Respiratory Rate	1 - 150 bpm
FiO2 Range	21 - 100%
HFOV Frequency	5 - 20 Hz
Power Supply	100-240 V AC, 50/60 Hz
Modes of Ventilation	SIMV, CPAP, HFOV
Tidal Volume Range	2 to 300 ml
PEEP/CPAP	0-20 cmH2O
Inspiratory Time	0.1 to 3 seconds
Flow Rate	2 - 30 L/min
Flow Sensor	Integrated
Pressure Limit	10-80 cmH2O
