93
Refer to Section 3.6.2 for connection.
2. New task
Select the “pressure transmitter” icon in the test type list, and input the information of the
calibrated pressure transmitter in turn:
Item
Effective value
Description
Name
Letter, numeral, symbol
Name of the pressure transmitter
Serial number
Letter, numeral, symbol
Serial number of the pressure transmitter
Model
Letter, numeral, symbol
Model of the pressure transmitter
Pressure type
Gauge pressure, absolute
pressure, differential
pressure
Pressure type of the pressure transmitter
Input
Depends on the pressure
transmitter
Pressure range of the pressure transmitter
Output
Analog signal: (4~20)mA,
(0~10)mA, (0~20)mA,
(1~5)V, (0~5)V, (0~10)V,
and custom
Electric signal output range of current/voltage and
pressure transmitters
HART device: Process
Electrical signal output type of HART device
