44
STATIC_PRESSURE_VALUE.
4. Transmitter operation
(1) Setup
After clicking , a function menu will pop up. Select "Setup" in the function menu to enter the
setup interface.
On the setup interface, you can access and set parameters in the Physical Block, Transducer Block
and Function Block.
Before modification of some parameters, you may need to modify corresponding TARGET_MODE
(e.g. set it to OOS, Auto, Man, and so forth). Specifically, you can follow the user manual of PA
transmitter to modify related parameters.
(2) Calibration
Click , then a function menu will pop up. Select "Calibrate" in the function menu to enter the
calibration interface.
You can calibrate the PA transmitter on the calibration interface. Before performing calibration on
the PA transmitter, please refer to relevant description of adjustment (Trim) part in the user manual
of PA transmitter.
3.4 Electrical output
You can click a corresponding electrical output icon in the module display/hide operation area on the
top status bar, to display/hide the electrical signal output module. When the electrical output is
displayed, the corresponding icon on the status bar will be highlighted. When the electrical output is
