Additel 761A - 2.1.3 Keypad

13
④⑤
Current, Voltage and power output, Red is positive ,
Black is negative
③
Jack A for connecting external pressure module
⑥
Jack B for connecting external pressure module
DC27V
Power adapter connection port
LAN
Ethernet interface
USB-A
Flash drive connection
USB-B
Computer connection
Table 2- 1 Electrical and signal port
2.1.3 Keypad
Item
Keypad
Description
1
On/Off Key: Power
2
Shortcut Key: Pressure vent
3
Shortcut Key: Pressure measure
4
Shortcut Key: Control pressure
