Additel 761A - External Pressure Module

48
Item
Effective value
Description
Range
Do not exceed the electrical output
range
Set the ramp output range.
Rise time
1~60 sec
Ramp rise time
Fall time
1~60 sec
Ramp fall time
0% wait time
1~60 sec
Wait time of the slope at the lower range value.
100% wait time
1~60 sec
Wait time of the slope at the upper range value.
Repeat
0-100
Set the cycle number of slope. 0 indicates infinite
repetition.
Table 3- 6 Ramp parameters
3.5 External pressure module
1. Connection: Connect the external pressure module as shown in Figure 3-11.
2. Display of the external pressure module
 When the pressure module is connected properly, the status bar will display the online icon of
pressure module. The calibrator supports two external pressure modules A and B, and provides
multi-screen display with other parameters. When the external pressure modules A and B are both
connected, the calibrator can show upto five items in the multi-screen.
 If the measured value exceeds the present range of pressure module, it will turn red and give an
alarm.
