Additel 761A - 5.4.4 Barometric altimeter

124
Figure 5- 10 Calibration of the barometric altimeter
5.4.4 Barometric altimeter
1. Connection
 Connect the calibrator and the barometric altimeter as shown in Figure 5-10.
2. New task
Select the “barometric altimeter” in the test type list, and input the information of the barometric
altimeter
Item
Effective value
Description
Name
Letter, numeral, symbol
Name of the barometric altimeter
