125
Serial number
Letter, numeral, symbol
Serial number of the barometric altimeter
Model
Letter, numeral, symbol
Model of the barometric altimeter
Calibration range
Depends on the barometric
altimeter
The input upper and lower limits can’t be equal. Pay
attention to the range of the calibrated device, or
otherwise the tested device may be damaged,
and the units of calibrated range shall only be meter
and feet in height
Rounding of reading
1, 0.1, 0.01
Rounding format of the reading
Allowable error
Depends on the pressure
gauge
Set the absolute allowable error of the segment
Owner
Letter, numeral, symbol
Owner of the barometric altimeter
Location
Letter, numeral, symbol
Locationof the barometric altimeter
Notes
Letter, numeral, symbol
Notes of the barometric altimeter
Table 5- 14 Task mode barometric altimeter
3. Task setting
For the contents, refer to Section 5.2.1 Task setting for calibration of the analog pressure gauge.
4. Task start
For the contents, refer to Section 5.2.1 Task start for calibration of the analog pressure gauge.
5. Task end
For the contents, refer to Section 5.2.1 Task end for calibration of the analog pressure gauge.
