92
gauge.
2. New task
Select the “digital pressure gauge” icon in the test type list. The other contents are the same as
those in Section 5.2.1 New Task for Calibration of the analog pressure gauge. The accuracy setting
for calibration of the digital pressure gauge is slightly different from the analog pressure gauge. The
effective values of the accuracy for calibration of the digital pressure gauge are 0.025%, 0.05%, 0.1%,
0.16%, 0.25%, 0.4%, 1 %, 1.6%, 2.5%, 4%, and custom.
3. For the contents of task setting, refer to Section 5.2.1 Task setting for calibration of the analog
pressure gauge. There are no settings for tapping and input format for calibration of the digital
pressure gauge.
4. For the contents of task start, refer to Section 5.2.1 task start for calibration of the analog pressure
gauge.
5. For the contents of task end, refer to Section 5.2.1 task end for calibration of the analog pressure
gauge.
5.2.3 Calibrate a pressure transmitter
During the task, the calibrator can automatically measure and record the current or voltage value
output from the transmitter.
1. Connection
