Same as Section 5.1.2 Pressure transmitter.
5.1.5 I/P converter
Select the “I/P converter” icon in the test type list to start the quick test.
1. Connection
 Connect as shown in Figure 3-21.
2. Start the test
Same as Section 5.1.2 Pressure transmitter.
3. Save the result
Same as Section 5.1.2 Pressure transmitter.
5.1.6 Signal isolator
Select the “signal isolator” icon in the test type list to start the quick test.
1. Connection
 Connect as shown in Figure 5-3.
2. Start the test
Same as Section 5.1.2 Pressure transmitter.
3. Save the result
Same as Section 5.1.2 Pressure transmitter.
