85
5.2 Task
The calibrator provides task functions which automate preset calibration routines, and collect, record,
and save test data.
Enter the task interface: Click , and select the task in the menu .
Task list interface: Click on the right side of the screen to create a new task, click to delete
tasks, and click to create a new folder.
Test parameter interface: Click on the right side of the screen to delete the task, click to
edit the task, click to copy the task, and click to start the task.
5.2.1 Analog pressure gauge
1. Connection
Connect the calibrator and the analog pressure gauge as shown in Figure 3-14.
It is recommended to connect the reference port (REF) when calibrating a differential pressure
device.
2. New task
Select the “analog pressure gauge” icon in the test type list, and input the information of the
pressure gauge.
