Input the number of cycles.
4. Task start
Click on the right side of the screen to zero the calibrator.
Click the execution button to start the task.
The upper left of the screen indicates the reading value of the current control pressure, and the
upper right indicates the switch state.
During the test, it can click the graph display button and the table display button to
switch to graph display or table display.
The switch action status and action value will be recorded and displayed in the table interface
When the internal pressure module is selected as the standard, the pressure switch test method is
based on slew rate in the control settings and the rate is gradually attenuated following the change
of state for the switch.
When using an external pressure module, the control must be done manually.
Click the stop icon at the bottom right of the screen to end the task.
5. Task end
For the contents, refer to Section 5.2.1 Task end for calibration of the analog pressure gauge.
5.2.6 I/P converter
