114
The following are required fields: Name and serial number, click OK button to complete the
save.
Click the back button to return to the test type list interface without saving.
IClick the reset button to rerun the test.
5.3.2 Mercury barometer
1. Prepare
Select “mercury barometer” in the test type list to enter to the quick test process of the mercury
barometer.
2. Connection
Connect to the calibrator as shown in Figure 5-8.
3. Start the test
Click the start button to select the automatic execution to enter the execution parameter setting
interface. Fill in the set point list, the number of cycles, the stroke mode, the number of readings,
the reading interval, and the dwell time, and then click the OK button to start the test. During
the testreadings will need to be manually inputed.
When selecting the next button , it will skip the current set point and advance to the next set
point.
Selecting the manual execution requiresreadings and set points to be manually inputed.
