Click the next point button toskip the current set point and advance to the next set point.
Select manual execution requires to input a new set point after inputting the reading every time;
To stop the test, press the back button .
4. Save the result
Click the save button to save the test results.
Required fields are as follows: Name and serial number, then click OK button to save.
Click the back button to return to the test type list interface to exit without saving the results.
To restart the test, click the reset button to return to the ready to start test interface.
5.3.5 Pressure transmitter
Same as Section 5.1.2 Pressure transmitter.
5.3.6 Pressure switch
Same as Section 5.1.3 Pressure switch.
5.4 Task (for barometric (BP) version)
5.4.1 Digital barometer
1. Connection
If calibrating the general digital barometer, connect the calibrator and the general digital barometer
as shown in Figure 5-6.
