80
5. Documentation
5.1 Quick test
Click the main menu icon on the main interface, and then select the icon to enter the quick
test function, and the calibrator displays the test type list. The quick test function doesn’t require test
information to be entered in advance.
5.1.1 Pressure gauge
Select the “pressure gauge” icon in the test type list to start the quick test of the pressure gauge.
1. Connection
Connect as shown in Figure 3-16 when testing an analog gauge;.
Connect as shown in Figure 5-1 when testing a digital pressure gauge.
2. Start the test
Click the zeroing button to reset the pressure control module.
Click the start button to select the automatic execution to enter the execution parameter
setting interface. Fill in the set point list, the number of cycles, the stroke mode, the number of
readings, the reading interval, and the dwell time, and then click the OK button to start the test.
The test data will be manually entered at each point of the test.
Click the next icon to skip the current test point and enter the next test point for pressure
