 When the DHCP mode is selected, the content of the table below will be allocated by the system
automatically and are read-only items.
 When the static mode is selected, the following table needs to be completed manually.
Item
Effective value
Description
I/P address
0.0.0.0~255.255.255.255
Set the IP address of calibrator host.
Subnet mask
0.0.0.0~255.255.255.255
Set the subnet mask of calibrator host.
Gateway
0.0.0.0~255.255.255.255
Set the source gateway of calibrator host.
Table 4-2 static mode selection
 The port number and physical address are factory settings and cannot be modified.
 Click the button at the lower right corner of screen confirms and saves the settings.
4.2.2 Wireless communication
The calibrator is connected via a wireless network.
Item
Effective value
Description
I/P address
0.0.0.0~255.255.255.255
Set the IP address of calibrator host.
Subnet mask
0.0.0.0~255.255.255.255
Set the subnet mask of calibrator host.
