Additel 761A - 4.2.3 Bluetooth

63
Gateway
0.0.0.0~255.255.255.255
Set the source gateway of calibrator host.
Table 4-3 Wireless network selection
 The port number and physical address are factory settings and cannot be modified.
 When the static mode is selected in advanced options, the following table needs to be completed
manually.
Item
Effective value
Description
I/P address
0.0.0.0~255.255.255.255
Set the IP address of calibrator host.
Subnet mask
0.0.0.0~255.255.255.255
Set the subnet mask of calibrator host.
Gateway
0.0.0.0~255.255.255.255
Set the source gateway of calibrator host.
Table 4-4Setup of wireless communication
 Click the button at the lower right corner of screen to confirm and save the settings.
 The setting of wireless communication will take effect immediately, with no need for confirmation.
Click 5 at the upper right corner of screen, to return to the previous menu.
4.2.3 Bluetooth
The calibrator is connected through Bluetooth to mobile APPs for communication.
