6. Application
6.1 Unit conversion
Click the menu in the upper right corner on the main interface to select the application, and then
enter the pressure unit converter.
Supports conversion between multiple pressure units.
6.2 Pressure leak test
There are two pressurization ways of pressure leak detection:
a) Calibrator pressurization: Select the internal high or low pressure range, and the calibrator
will automatically run the test.
b) External pressurization: Select an external pressure module and use external pressure
generation to run the leak test.
1. Setup
Select the application in the function menu to enter the pressure leak test.
Click the upper area on the interface to select the range: Select the internal module range or the
external pressure module.
1) If the external pressure module is selected, there is no need to set the pressure target value;.
Select the pressure unit: If the selected unit is not supported by the selected module, it will
To Next Page
