Pressure output module display/hidden: Icon and will be displayed according to pressure control range.
External pressure module A display/hidden: Icon will be displayed when pressure module A is connected.
External pressure module B display/hidden: Icon will be displayed when pressure module B is connected.
3. Navigation function area
◆ Control center: Click icon to enter the control center. The control center has many functions, such as internal
pressure module, electrical measurement signal, electrical output signal, external module A, external module B,
positive pressure air source and negative pressure air source, lock screen function, Bluetooth communication and
Wi-Fi communication open and close and so on.
◆ Notification center: when exceptions happen, The icon will turn to red and highlight. Click the icon to know more
information about the exception.
◆ Main menu: Click icon , the main menu provides system configuration, HART communicator, quick test, task and
application functions and so on.
3.1.2 Module and split screen display area
The module function display area is divided into electrical signal measuring area, electrical signal output area, external
pressure module A and B (once pressure modules are inserted). By clicking the "Module function display/hidden
operation area" in the status bar, above functions display areas can be shown and hidden, at the same time, the
module function can set screen quantity from one to five.
