7.2 HART communicator operation
Read the parameters in HART which may be modified. The root directory options are 1-4.
Depending on the HART device, the parameters that have been modified but not written in HART
are highlighted in yellow in the list. Click to finish the operation of writing into the HART device.
After entering, click on the right side of the screen to view the explanation information of some
parameters.
After entering the parameter editing interface, click the control center icon in the status bar to
copy the indications of the internal pressure module, А and В indications of the external pressure
modules, HART indications, and the electrical measurement indications.
Click and on the right side of the screen to view the communication status and the
device status respectively. After entering, the open circle on the right side of the list indicates that
there is no abnormality or it indicates that the item is abnormal
Click on the right side of the screen to return to the main interface of the device. To return to
the HART communicator again, click in the upper right corner of the screen.
